FRP / SS304 RO Plant 1000LPH Ultrafiltration Membrane System

    Buy cheap FRP / SS304 RO Plant 1000LPH Ultrafiltration Membrane System from wholesalers

    Buy cheap FRP / SS304 RO Plant 1000LPH Ultrafiltration Membrane System from wholesalers
    • Buy cheap FRP / SS304 RO Plant 1000LPH Ultrafiltration Membrane System from wholesalers

    FRP / SS304 RO Plant 1000LPH Ultrafiltration Membrane System

    Ask Lasest Price
    Brand Name : AJIEWATER
    Model Number : AJ
    Certification : ISO9001, CE, SGS
    Price : Negotiation
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : >300sets/month
    Delivery Time : 1-7working days(depand on raw materials stocking)
    • Product Details
    • Company Profile

    FRP / SS304 RO Plant 1000LPH Ultrafiltration Membrane System

    380V 1000LPH Water Purification Systems FRP / SS304 Ro Plant For Commercial


    Detailed Product Description


    Items Name:380V 1000LPH Ultrafiltration Membrane SystemProduction Capacity:1000liters Per Hour
    Electrical Power:220V / 380V 50Hz / 60HzTank Material:FRP / Stainless Steel
    Control Valve:Automatic / ManualPipe Fitting:SUS304 / U-PVC
    Warranty:1 YearOptional:Ozone/ UV / Water Softener
    Prefiltering Tank:Glass Fiber / FRP

    380V 1000LPH Ultrafiltration Membrane System FRP / SS304 Ro Plant For Commercial Use

    Ultra-filtration (UF) is a membrane separation technology that purifies and separates solutions. The ultrafiltration membrane system is a solution separation device in which an ultrafiltration membrane is as a filter medium and a pressure difference on both sides of the membrane is a driving force. The ultrafiltration membrane only allows the solvent (such as water molecules), inorganic salts and small molecular organic substances in the solution to pass through, and the macromolecular substances such as suspended matter, colloid, protein and microorganisms in the solution are intercepted, thereby purifying or separating.


    Ultrafiltration (UF) Systems Advantages

    Ultrafiltration (UF) membranes systems are more reliable than a conventional multi-media filter, which removed approximately 10 micron or larger of matter, where an ultrafiltration membrane pore size ranges from 0.01 to 0.10 micron. In addition to superior turbidity removal, UF membranes efficiently remove bacteria and most viruses.


    - Superior filtration performance with high flux

    - Very small nominal pore diameter (0.03 µm)

    - Efficiently removes bacteria and viruses

    - Occasionally back washed and air scoured to boost performance and removing the fouling layer to extend operating life

    - Low fouling membrane modules

    - UF Outside-In or Inside-Out Configuration permits reduced plugging and higher solids loading

    - Basic, vertical, modular design permits low cost, compact systems

    - Effective membrane cleaning has a high chemical resistance and temperature tolerance


    Ultrafiltration (UF) Systems Features

    ♦Polyethersulfone material, higher mechanical strength, excellent performance for chemical tolerance.
    ♦Single inner layer sponge-type structure, higher permeate flux, better interception performance
    ♦Permanent hydrophilicity, lower deep fouling, steady flux, easier recovery after cleaning
    ♦Thicker membrane separation layer, better antifouling performance, higher mechanical strength


    Application of UF Waste Water Treatment Plant:


    The UF System is widely used in water production corporations, factory or schools as drinking water treatment system. The application including :


    1. Surface Water Clarification
    2. RO System Pre-Treatment
    3. Waste Water or Sewage Treatment
    We can accord to clients requirement supply the completely mineral water plant with bottle water filling and cover and labelling all in one .


    UF System Configuration:


    UF Membrane module
    Valves & Meters
    Control System
    Pipes and Fitting
    304 stainless Skid Frame
    Preccision Filter
    Raw water pump
