Brand Name : | AJIEWATER |
Model Number : | AJ |
Certification : | ISO9001/CCS/CE |
Price : | Negotiation |
Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability : | >300sets/month |
Delivery Time : | 1-7working days(depand on raw materials stocking) |
500LPH Seawater Desalination System / Purifying Machine For Direct
Bottle Drinking
Detailed Product Description
RO Membrane: | USA DOW | Production Capacity: | 500liters Per Hour |
---|---|---|---|
Recovery Rate: | 50%-75% | Electrical Power: | 220/380V 50/60Hz |
Tank Material: | FRP/ Stainless Steel/ Carbon Steel | Control Valve: | Automatic/ Manual |
Pipe Fitting: | SUS304/ U-PVC | Warranty: | 1 Year |
High Light: | seawater reverse osmosis system, reverse osmosis desalination system |
500LPH RO Water Treatment System / Purifying Machine For Drinking
1. Product Description
Reverse osmosis system is using city water as raw water, then treat
water by Pre-filter (water softener is optional), reverse osmosis
membrane.
It can remove particle, colloid, organic impurity, heavy metal ion,
bacteria, virus in water, and it can also remove 99% dissolved
salt.
The whole system desalination rate can reach 96%-99% to make
permeated water conductivity<10 us/cm. Dense water also won't
polluted environment.
Reverse osmosis equipment no need to consider about input water
quality too much. And the main features of RO equipment is no need
to do any regeneration, it can be keep stable for long time.
2. Product Parameter
kyro-500LPH RO Water Treatment System: |
1. Capacity: 5000L/H |
2. Rated power: 1.5KW/H |
3. Voltage: 110V/220V/380V, 50Hz/60Hz, single phase/3phase |
4. Desalting rate:>=97% |
5. Water recovery rate: 50-75% |
6. Conductivity of raw water: ≤400μs |
7. Conductivity of pure water: ≤10μs |
3. Application:
Feed water(source water):
City water, river water, lake water, underground water(borehole,
well), brackish water, sea water......
Treated water:
1. Electronic industry: Pre-filter for ultra pure water, chemical
products and pure water
2. Food and beverage industry: filter for mineral water, wines and
fruit juice
3. Medicine industry: filter for drug liquid, gases
4. Chemical industry: filter for organic solvent
5. Petroleum industry: filter for oil-field flooding
4. System Performance:
*Main part (membrane) of reverse osmosis system is imported from
USA.
*Auto stop when no water and full water.
*Auto controller, RO membrane auto flush to protect membrane.
*Auto start when pure water tank have no water.
*Low pressure protection switch to protect high pressure pump when
there is no raw water.
*High efficient and low noise high pressure pump.
*Product water conductivity meter to monitor product water quality
all the time.
*Input water and output water pressure gauge to monitor RO membrane
*differential pressure to remind it's time for chemical cleaning.
*Inlet water solenoid valve to stop water when machine is stop.
5. Product Processing
1. Raw/Pure Water Tank(PE) | 2. Water Tank Stainless Steel Rack |
3. Regulating Wheels | 4. Raw Water Pump |
5. Quartz Sand Filter | 6. Activated Carbon Filter |
7. Automatic Control Valve | 8. Inlet Water Pressure Gauge |
9. Outlet Water Pressure Gauge | 10. Security Filter |
11. High Pressure Pump | 12. Pure Water Conductivity Monitor |
13. PC Controller | 14. Touch Screen Control Panel |
15. Total Power | 16. Emergency Stop |
17. Ro Membrane | 18. Ultraviolet Sterilizer |
![]() |
